3000 GPD RO Industrial Water Treatment Plant

  1.  Product: 3000 GPD RO Industrial Water Treatment Plant
  2.  Stainless Steel Frame (Control box-Option)
  3.  20″ Prefilters x 3
  4.  Stainless Steel or Fiber Glass Membrane vessel
  5.  4″ x 40″ Membrane
  6.  Inlet Actuator & Flush Solenoid Valve
  7.  Source & Ro Gauge
  8.  Inlet & Concentration Flow Meter
  9.  S.steel Vertical Pump 1.1 kW (single phase motor)
  10.  Auto Flush Controller & TDS Detector
  11.  Pressure Regulator
  12.  Gate Valve
  13.  Anti-Scalent Device
  14.  Electricity consumption: 1120W
  15.  Dimension & Weight: 80X50X145 cm (78 kgs)


Ozone Spring 3000 GPD RO Industrial Water Treatment Plant is made up of equipment that is fully operational. Reverse osmosis membranes with great efficiency are used in these industrial RO systems to create low dissolved solids water from tap or well water. Ozone Spring RO systems are designed to work at pressures of 200-400 psi for higher TDS water and use reverse osmosis membranes. The RO membranes provide better salt removal and the higher operating pressure compensates for the decreased membrane flow caused by increased TDS levels.

Ozone Spring 3000 GPD RO Industrial Water Treatment Plant


  1.  Production Capacity:  3000GPD
  2.  Salt Rejection:  96-98%
  3.  Recovery Rate:  50-60%
  4.  Connection:  1” Feed, 3/4”Permeate, 3/4”Concentrate

Features of 3000 GPD RO Industrial Water Treatment Plant:

  1.  Computer Controll Panel
  2.  Low-Pressure Monitoring Alarm
  3.  Dual TDS Monitoring
  4.  Feed Flush
  5.  Tank Level Input
  6.  Vertical Multi-Stage Stainless Steel Booster Pump
  7.  Feed Solenoid Valve with Electronic Bypass
  8.  Feed Low-Pressure Switch
  9.  Pump High-Pressure Switch
  10.  Glycerin-filled panel-mounted gauges with a pre-filter (0–100 psi)
  11.  Panel Mounted Glycerin Filled Gauges for Pump Discharge and Concentrate at 0-600 psi
  12.  5 Micron Sediment Filter
  13.  O-Ring & Heavy-Duty Filter Housing
  14.  Low Energy Membrane Elements
  15.  Stainless Steel Membrane Housings-450 psi
  16.  Clean-in-place (CIP) Ports
  17.  High-Pressure Stainless Steel Tubing and Fittings
